小型混凝土搅拌车压力不足的原因有哪些?

 来源:http://www.jufengjiaobanji.com 日期:2021-12-06 发布人:jufeng
在一定的压力之下,小型混凝土搅拌车有了压力的作用,会产生一定的动力,开始了它的运行,这样上面的混凝土可以得到更充分地搅拌,在压力不足的前提下可能对搅拌车的效率有影响,那么要如何解决压力不足这个问题呢?
Under a certain pressure, the small concrete mixer has the function of pressure, will produce a certain power and start its operation, so that the concrete above can be mixed more fully. On the premise of insufficient pressure, it may affect the efficiency of the mixer. So how to solve the problem of insufficient pressure?
1、查看小型混凝土搅拌车液压泵是否能输出液压油,如果是新的液压泵,无液压油输出,可能是泵体有铸造缺陷(缩孔、砂眼等),使吸油腔和压油腔相通,失去压油能力,应及时找厂家更换,若不是新的液压泵,无液压油输出,可能是泵的转向不对,零件磨损严重或损坏,及时更换。
1. Check whether the hydraulic pump of small concrete mixer truck can output hydraulic oil. If it is a new hydraulic pump and there is no hydraulic oil output, it may be that the pump body has casting defects (shrinkage cavity, sand hole, etc.), which connects the oil suction chamber with the oil pressure chamber and loses the oil pressure capacity. It should be replaced by the manufacturer in time. If it is not a new hydraulic pump and there is no hydraulic oil output, it may be that the direction of the pump is wrong, If the parts are seriously worn or damaged, replace them in time.
2、若小型混凝土搅拌车液压泵有油液输出,查看溢流阀工作是否正常。若不正常,则可能是压力油路中的某个阀有污物或其他原因卡住,处于回油位置,致使压力油路与溢流回路短路,也可能是管接头松脱,或处于压力油路中的某些阀泄漏严重,或液压缸、液压马达的密封损坏,严重泄漏。排除方法是拆开有关阀进行清洗,检查密封间隙的大小及各种密封装置,密封装置损坏应更换。
2. If the hydraulic pump of small concrete mixer truck has oil output, check whether the overflow valve works normally. If it is abnormal, it may be that a valve in the pressure oil circuit is stuck due to dirt or other reasons and is in the oil return position, resulting in a short circuit between the pressure oil circuit and the overflow circuit, or the pipe joint is loose, or some valves in the pressure oil circuit leak seriously, or the seals of the hydraulic cylinder and hydraulic motor are damaged and leak seriously. The troubleshooting method is to disassemble the relevant valves for cleaning, check the size of sealing clearance and various sealing devices, and replace the damaged sealing devices.
3、若水泥小型混凝土搅拌车的液压泵输出流量随压力升高而显着减小,且压力达不到规定值,则是由于液压泵磨损后间隙加大所致。排除方法是测定液压泵的容积效率,即可确定该泵是否能继续使用,对磨损严重的零件,应进行修配或更换。
3. If the output flow of the hydraulic pump of the small cement concrete mixer decreases significantly with the increase of the pressure, and the pressure does not reach the specified value, it is due to the increase of the clearance after the hydraulic pump is worn. The elimination method is to measure the volumetric efficiency of the hydraulic pump to determine whether the pump can continue to be used. The severely worn parts should be repaired or replaced.
4、小型混凝土搅拌车的液压系统能建立正常压力,而某些管路或液压缸中无压力,可能是由于管路、小孔或节流阀、换向阀等部位堵塞。此时应逐段检查压力和有无油液通过,找出原因,加以排除。
4. The hydraulic system of small concrete mixer can establish normal pressure, but there is no pressure in some pipelines or hydraulic cylinders, which may be due to the blockage of pipelines, small holes, throttle valves, directional valves and other parts. At this time, check the pressure and oil passage section by section, find out the cause and eliminate it.
