The driving force of the full-automatic self feeding mixer is output by the full power take-off of the class II chassis. According to the transmission shaft, the driving force is transmitted to the hydraulic pump. The hydraulic energy formed by the hydraulic pump is transmitted to the hydraulic motor according to the oil pipe. The hydraulic motor converts the hydraulic energy into power and transmits it to the mixing tank according to the speed reduction and torque increase of the reducer.
After the application to the corresponding time, too much or too little will cause the mixing drum not to be able to rotate. There are usually three cases:
1. The concrete got stuck during transportation;
2. Hydraulic system or engine system failure;
3. The motor has a system fault.
1. The concrete got stuck during transportation; It's OK to clean it up;
2. Disposal of hydraulic system or engine fault:
(1) Open the manhole cover of the mixing drum, loosen the pipe joint of the high-pressure hose on the motor, rotate the mixing drum so that the manhole of the mixing drum is inclined downward, and discharge the concrete from the manhole of the mixing drum;
(2) Unload the high-pressure hose of the fault vehicle from the motor, connect the high-pressure hose for rescue, connect the other end to the oil pump of the rescue vehicle, connect one side of the emergency oil return pipe to the motor oil drain port of the fault vehicle, and connect the other end of the oil return pipe to the oil return port of the oil pump of the rescue vehicle. Use the rescue vehicle to adjust the rotation of the mixing cylinder of the fault vehicle and discharge the concrete.
3. If there is a system fault in the motor, the disposal is relatively simple. The motor of the rescue vehicle can be unloaded and installed on the system fault vehicle, and then each oil pipe can be connected, and the concrete in the mixing drum can be discharged by running the rescue vehicle.
