One of his former colleagues recently called to say that his cooling fan had broken down, affecting operations. I was asked why. After asking about the fault and his solution, I suspect that the fault was burned by the insurance. After replacing the new insurance, the problem was solved. Today Xiaobian will talk about the hydraulic oil cooling system of the cement mixer with us.
The tank operated cement mixer is driven by hydraulic pressure. The hydraulic oil flows in the pipeline at a certain speed for a long time, and rubs against the wall of the pipeline. In addition to the pipeline resistance in various valves and the work of the oil pump, the hydraulic oil will generate heat and the oil temperature will rise by compressing the hydraulic oil. If the hydraulic oil works normally, a certain temperature is a good thing, but if the temperature range is too large, it will not only make the whole working system unstable, but also damage the oil seal, aggravating the oxidation and deterioration of the hydraulic oil.
The hydraulic oil cooling system of the concrete mixer is generally composed of the following four parts, of which the most likely failure is to protect the entire circuit, so when you open the concrete mixer, friends and other problems, check whether the insurance is normal for the first time, and then the fault diagnosis of other parts.
The heat exchanger is like a hydraulic tank to cool it
Just as the engine heats, the concrete mixer is cooled by a hydraulic oil radiator. The heat exchanger (also known as heat sink) is equipped with a fan driven by a motor, which forces heat dissipation to keep the hydraulic oil within the normal working range.
By detecting the negative pressure of the pipeline, the mechanical pointer proves that the hydraulic oil filter may be blocked. If there is a reading, at first only the rubber plug with zero pointer needs to be deleted. If there is still a reading and the rubber plug still cannot be solved, the hydraulic oil filter needs to be replaced.
The fan driven by the motor takes away the heat of the hydraulic oil
The motor is the most important part of the whole cooling system. The cooling effect is directly related to the speed and running state of the motor. It is powered directly by an electric box connected to the car battery, which drives a motor to run at high speed, takes heat away from the heat exchanger and cools the hydraulic fluid.
Temperature sensor detects the temperature of hydraulic oil
A sensor is installed on the water inlet pipe of the heat exchanger to detect the temperature of the hydraulic oil entering the heat exchanger.
The control box is the brain that controls the hydraulic oil not to be heated
The control box is the brain of the whole cooling system, similar to the ECU of the vehicle. Analyze the data transmitted by the temperature sensor. After the temperature value is exceeded, connect the cooling motor circuit, and run the motor to take away the temperature in the hydraulic oil. It has a safety cover on the top to protect the whole circuit, so that the control box is not easy to damage.
Well, let's talk about its principle. After the cooling system fails, the motor does not run. For the most economical and time-saving troubleshooting sequence, please check the fuse in the following order - replace the temperature sensor - replace the motor - replace the control box
